How to add cable heads to cable trays

Adding cable heads to cable trays involves securely terminating or connecting cables at the tray ends while ensuring proper support, spacing, and grounding.Step 1: Plan and PrepareBefore adding cable heads, plan the cable tray route and determine where the cable terminations will occur. Ensure the tray is properly mounted and supported according to manufacturer specifications, typically every 1.5 to 3 meters depending on load and tray type (ladder, perforated, or ventilated trough) to prevent sagging or stress on the cable heads . Clear the pathway of obstructions and verify compliance with local electrical codes.Step 2: Select Appropriate Cable HeadsCable heads (terminations or connectors) must match the cable type and voltage rating. For power cables, use insulated lugs or gland-type terminations; for control or instrumentation cables, use appropriate multi-conductor connectors. Ensure the cable head is rated for the environment (indoor, outdoor, or corrosive conditions).Step 3: Secure Cables in the TrayLay the cables along the tray, keeping them organized and avoiding sharp bends. Ladder trays allow easy placement between rungs, while ventilated troughs provide continuous support .Use cable ties or clamps to secure cables near the tray ends, ensuring the cable head will not bear the weight of the cable itself .Maintain proper spacing to prevent overheating and adhere to fill ratios (usually max 50% of tray capacity) as per NEC 392.22 .Step 4: Install Cable HeadsPosition the cable head at the tray termination point or at the equipment entry.Attach the cable head to the cable according to manufacturer instructions, ensuring a tight and secure connection.Support the cable head using a short section of tray, a bracket, or a strain relief clamp to prevent mechanical stress on the termination .Step 5: Grounding and BondingIf the cable tray serves as an Equipment Grounding Conductor (EGC), ensure the cable head is properly bonded to the tray system. All tray sections should be electrically continuous and securely bonded to meet NEC 392.60 requirements .Step 6: Inspection and TestingAfter installation, inspect all cable heads for secure connections, proper support, and absence of sharp edges that could damage insulation. Test continuity and grounding as required to ensure safety and compliance. By following these steps, cable heads can be safely and efficiently added to cable trays, maintaining both mechanical integrity and electrical safety.
